<Vari-focal Lens with Auto Iris> --- Optional Lens
1.
Mount the CS-mount lens by turning it clockwise onto the camera mount until it
stops.
2.
If it's necessary, please turn the lens counterclockwise slowly until it gets the best
position.
3.
Connect the lens cable plug (DC Iris control cable) to the camera side connector.
1.
Unscrew the zoom controller to adjust the zoom factor. Upon completion, tighten the
zoom controller.
2.
Unscrew the focus controller to adjust the focus range. Upon completion, tighten the
focus controller.
# For further information of vari-focal lens with auto iris, please refer to the supplied
lens' instruction manual.
