Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page; any changes made locally will be undone.

4.2.2 IP Configuration

The IP Configuration includes the IP Address, Subnet Mask and Gateway. The Configured column is
used to view or change the IP configuration. Fill up the IP Address, Subnet Mask and Gateway for the
device. The screen in
The Current column is used to show the active IP configuration.
Object
• DHCP Client
•
IP Address
•
IP Mask
•
IP Router
• VLAN ID
Figure 4-2-2 appears.
Figure 4-2-2: IP Configuration page screenshot
Description
Enable the DHCP client by checking this box. If DHCP fails and the
configured IP address is zero, DHCP will retry. If DHCP fails and the
configured IP address is non-zero, DHCP will stop and the configured IP
settings will be used. The DHCP client will announce the configured
System Name as hostname to provide DNS lookup.
Provide the IP address of this switch in dotted decimal notation.
Provide the IP mask of this switch dotted decimal notation.
Provide the IP address of the router in dotted decimal notation.
Provide the managed VLAN ID. The allowed range is 1 through 4095.
52
