Object
• Local Port
• Chassis ID
• Remote Port ID
• System Name
• Port Description
• System Capabilities
• Management
Address
Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
Description
The port on which the LLDP frame was received.
The Chassis ID is the identification of the neighbor's LLDP frames.
The Remote Port ID is the identification of the neighbor port.
System Name is the name advertised by the neighbor unit.
Port Description is the port description advertised by the
neighbor unit.
System Capabilities describes the neighbor unit's capabilities. The
possible capabilities are:
1. Other
2. Repeater
3. Bridge
4. WLAN Access Point
5. Router
6. Telephone
7. DOCSIS cable device
8. Station only
9. Reserved
When a capability is enabled, the capability is followed by (+). If
the capability is disabled, the capability is followed by (-).
Management Address is the neighbor unit's address that is used
for higher layer entities to assist the discovery by the network
management. This could for instance hold the neighbor's IP
address.
