To implement QoS on your network, you need to carry out the following actions:
1. Define a service level to determine the priority that will be applied to traffic.
2. Apply a classifier to determine how the incoming traffic will be classified and thus treated by the
Switch.
3. Create a QoS profile which associates a service level and a classifier.
4. Apply a QoS profile to a port(s).

4.9.2 Port Policing

This page allows you to configure the Policer settings for all switch ports. The Port Policing screen in
Figure 4-9-1 appears.
The page includes the following fields:
Object
• Port
• Enable
• Rate
•
Unit
Buttons
Figure 4-9-1: QoS Ingress Port Policers page screenshot
Description
The port number for which the configuration below applies.
Controls whether the policer is enabled on this switch port.
Controls the rate for the policer. The default value is "500". This
value is restricted to 100-1000000 when the "Rate Unit" is "kbps"
or "fps", and it is restricted to 1-15000 when the "Policer Unit" is
"Mbps" or "kfps".
Controls the unit of measure for the policer rate as kbps, Mbps,
fps or kfps . The default value is "kbps".
185
