Buttons
:
Click to refresh the page immediately.
Auto-refresh
: Check this box to enable an automatic refresh of the page at regular intervals.

4.11.5 Network Access Statistics

This page provides detailed NAS statistics for a specific switch port running EAPOL-based IEEE
802.1X authentication. For MAC-based ports, it shows selected backend server (RADIUS
Authentication Server) statistics, only. Use the port select box to select which port details to be
displayed. The Network Access Statistics screen in
The page includes the following fields:
Port State
Object
• Admin State
• Port State
• QoS Class
• Port VLAN ID
"(RADIUS-assigned)" is appended to the VLAN ID. Read
more about RADIUS-assigned VLANs here.
If the port is moved to the Guest VLAN, "(Guest)" is
appended to the VLAN ID. Read more about Guest VLANs
here.
Figure 4-11-6: Network Access Statistics page screenshot
Description
The port's current administrative state. Refer to NAS Admin State
for a description of possible values.
The current state of the port. Refer to NAS Port State for a
description of the individual states.
The QoS class assigned by the RADIUS server. The field is blank if
no QoS class is assigned.
The VLAN ID that NAS has put the port in. The field is blank, if the
Port VLAN ID is not overridden by NAS.
Figure 4-11-6
247
IFS NS3502-8P-2S User Manual
appears.
