The page includes the following fields:
Object
• Frame Type
•
Enable
•
Rate
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.

4.9.14 QoS Statistics

This page provides statistics for the different queues for all switch ports. The QoS Statistics screen in
Figure 4-9-17 appears.
Figure 4-9-16: Storm Control Configuration page screenshot
Description
The settings in a particular row apply to the frame type listed
here:
unicast
multicast
Enable or disable the storm control status for the given frame
type.
The rate unit is packets per second (pps). Valid values are: 1, 2, 4,
8, 16, 32, 64, 128, 256, 512, 1K, 2K, 4K, 8K, 16K, 32K, 64K, 128K,
256K, 512K , 1024K, 2048K, 4096K, 8192K, 16384K or 32768K.
207
