Led Indications - Interlogix IFS NS3502-8P-2S User Manual

Reset Button Pressed and
Released
< 5 sec: System reboot
> 10 sec: Factory Default

2.1.2 LED Indications

The front panel LEDs indicates instant status of port links, data activity and system power; helps
monitor and troubleshoot when needed.
Switches.
NS3502-8P-2S LED indication
System
LED Color
FAN Alert Green
PWR Green
Function
Reboot the Managed Switch
Reset the Managed Switch to Factory Default
configuration. The Managed Switch will then
reboot and load the default settings as below:
。
。
。
。
。
Figure 2-2
Figure 2-2: NS3502-8P-2S LED panel
Lights to indicate that the fan is fail.
Lights to indicate that the Switch has power.
Default Username: admin
Default Password: admin
Default IP address: 192.168.0.100
Subnet mask: 255.255.255.0
Default Gateway: 192.168.0.254
shows the LED indications of these Managed
30
IFS NS3502-8P-2S User Manual
Function
