none
Example:
Set DSCP classification based on QoS class and DP level in zero
NS3502-8P-2S:/> QoS Port DSCP Classification 1-10 zero

QoS Port DSCP EgressRemark

Description:
Set or show the port DSCP remarking mode.
Syntax:
QoS Port DSCP EgressRemark [<port_list>]
[disable|enable|remap_dp_unaware|remap_dp_aware]
Parameters:
<port_list>: Port list or 'all', default: All ports
disable
enable
remap_dp_unaware : Rewrite DSCP in egress frame with remapped DSCP where remap is DP
unaware or DP = 0
remap_dp_aware
aware and DP = 1
(default: Show port DSCP egress remarking mode)
Default Setting:
disable
Example:
Enable DSCP egress rewrite
NS3502-8P-2S:/> QoS Port DSCP EgressRemark 1-10 enable

QoS DSCP Map

Description:
Set or show DSCP mapping table.
This table is used to map QoS class and DP level based on DSCP value.
: Disable DSCP egress rewrite
: Enable DSCP egress rewrite with the value received from analyzer
: Rewrite DSCP in egress frame with remapped DSCP where remap is DP
501
