• Port
• Mode
• Port Descr
• Sys Name
•
Sys Descr
• Sys Capa
• Mgmt Addr
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
The switch port number of the logical LLDP port.
Select LLDP mode.
Rx only The switch will not send out LLDP information, but LLDP
information from neighbor units is analyzed.
Tx only The switch will drop LLDP information received from
neighbors, but will send out LLDP information.
Disabled The switch will not send out LLDP information, and will
drop LLDP information received from neighbors.
Enabled The switch will send out LLDP information, and will
analyze LLDP information received from neighbors.
Optional TLV: When checked the "port description" is included in
LLDP information transmitted.
Optional TLV: When checked the "system name" is included in
LLDP information transmitted.
Optional TLV: When checked the "system description" is included
in LLDP information transmitted.
Optional TLV: When checked the "system capability" is included
in LLDP information transmitted.
The system capabilities identify the primary function(s) of the
system and whether or not these primary functions are enabled.
The information advertised by this TLV is described in IEEE
802.1AB.
Optional TLV: When checked the "management address" is
included in LLDP information transmitted.
The management address protocol packet includes the IPv4
address of the switch. If no management address is available, the
address should be the MAC address for the CPU or for the port
sending this advertisement. The management address TLV may
also include information about the specific interface associated
with this address, and an object identifier indicating the type of
hardware component or protocol entity associated with this
address
