Object
•
IPv6 Address
•
Ping Size
Buttons
: Click to transmit ICMP packets.

4.15.3 Remote IP Ping Test

This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues on special port.
After you press "Test", 5 ICMP packets are transmitted, and the sequence number and roundtrip time
are displayed upon reception of a reply. The page refreshes automatically until responses to all packets
are received, or until a timeout occurs. The ICMP Ping screen in
The page includes the following fields:
Object
• Port
• Remote IP Address
Description
The destination IPv6 Address.
The payload size of the ICMPv6 packet. Values range from 8 bytes
to 1400 bytes.
Figure 4-15-3: Remote IP Ping Test page screenshot
Description
The logical port for the settings.
The destination IP Address.
Figure 4-15-3
321
IFS NS3502-8P-2S User Manual
appears.
