 When the cash register is connected to an electric scale, the SCALE button is used to read the
weight of the weighed goods. In the „P" mode this key is used to print out all the programmed
parameters in the given item.
 The SHIFT key advances the receipt ribbon without printing. Pressing the button moves the paper
ribbon by about 1.5 cm.
 The MULTIPLY button is used for multiplication if two or more of the same item are being sold.
 The DIVIDE button is used for sales of fractional amounts.
The PRICE button enables the manual entry of a price rather than registering the preprogram-

med PLU price for one item. It is also used for fast PLU price programming in the "P" mode.
After completing a transaction, it is possible to print out a duplicate receipt by pressing the DU-

PLICATE button. The receipt is marked as "KOPIERA", printed in double-sized letters. Only one
duplicate of each receipt can be printed.
In "T" mode, stop and start print on the receipt.

The PLU button (PRICE LOOK UP) enables you to call up the programmed data about an item,

price, name, department, VAT, etc..
 The CREDIT button is used to finalise a sale when payment is made with a credit card.
The CHECK button is used to select the type of payment when payment is made by check. In

the „P" mode it is used to print out programmed data.
 
and These two buttons are used for adding a percent surcharge or subtracting a percent discount for
a iven item or for a complete transaction according to the programmed values.
 
and
for a given item or for a complete transaction.

The SUBTOTAL button displays and prints out the current subtotal value.
The TOTAL/CASH button is used to finalise a sale when payment is made in cash. In the cash

register menu this button serves to transition to a sub-menu or confirmation of a selected/entered
value.
 The MENU button is used to call up the cash register menu. With the menu open, this key serves
to shift the selected level up one line.

upon opening a sale, the
 The ON/OFF key is used for switching the cash register on and off. This key is also used to wake
the cash register up from the Power-saving mode.

DESCRIPTION OD DISPLAYS

Description of the cashier display

The cashier display is a double-line LCD display with 16 characters per line.
These two buttons are used for adding a value surcharge or subtracting a value discount
The arrow keys serve for movement within the cash register menus. In the "R" mode,

Figure 2.4 – Alphanumeric LCD display
R
keys serve for the moving of individual registered product items.
15-02-2008
11:07:39
Cash register characteristics
17
