Technical Information

Power requirements

Apple Desktop Bus
Maximum power draw for all devices: 500 mA
Mouse power: up to 10 mA
Keyboard power: 25Ð80 mA (depending on keyboard model)
Audio and telecommunications input devices
Device
Microphone
GeoPort Telecom Adapter
Expansion cards and devices
When you add PCI cards, NuBus cards or internal storage devices, make sure the combined
power consumption of all devices meets the following guidelines:
Device
PCI or NuBus card (per slot)
PCI or NuBus cards total
(5 slot maximum)
Internal storage device (such as a
CD-ROM or hard disk drive)
70
PowerWave 604 UserÕs Guide
Voltage Current
+5 V 20 mA
+5 V 500 mA
Voltage Current
+5 V 3 A
+12 V 0.5 A
-12 V 0.1 A
+5 V 10 A
+12 V 2.5 A
-12 V 0.5 A
+5 V 4.5 A
+12 V 1.7 A
For Technical Support, Call 1-800-708-6227
Power
100 mW
2.5 W
Power
15 W
6.0 W
1.2 W
50 W
30 W
6 W
22.5 W
20 W
