Upgrading Your Computer
Removing a DIMM.
1.
If you need to remove a DIMM module to make room for a higher-capacity
one, reach in and push down on the tiny lever at the end of the DIMM slot.
lever
1. push
lever
down
2.
The DIMM should pop loose from the slot at the lever end.
3.
If the DIMM module does not come free, press the DIMM lever down again.
4.
Grasp the DIMM module with one hand at each end and pull the module up
and out of the slot.
5.
When you are Þnished with DIMM removal and insertion, replace the end
panel (if you are removing RAM from a tower system), and replace the
cover.
28
PowerWave 604 UserÕs Guide
2. lift DIMM out
