To Install An Expansion Card - Power Computing PowerWave 604 User Manual

Upgrading Your Computer

To install an expansion card:

1.
Remove the computerÕs cover.
See ÒRemoving the cover,Ó starting on page 15 for instructions.
Make sure the computer is powered down before removing the cover.
WARNING!
Touch the metal plate over the hard disk drive to discharge any static
CAUTION!
electricity that might have built up on your clothes or body.
Use a grounding strap and handle memory modules by the non-metallic
edges only.
2.
If you are installing the card in a tower system, remove the two screws
securing the end panel to the chassis and put them in your left front pocket
or somewhere else where you will be able to Þnd them later. (There is no
end panel on the desktop system.)
Lift the panel from the chassis and set it aside.
riser card
22
PowerWave 604 UserÕs Guide
end panel of chassis
Discharge Static
screws
For Technical Support, Call 1-800-708-6227
