Inserting a DIMM
CAUTION! Touch the metal plate over the hard disk drive to discharge any static
electricity that might have built up on your clothes or body.
Use a grounding strap and handle memory modules by the non-metallic
edges only.
1.
To insert a DIMM module, hold the module with one hand at each end with
the contacts down and the chip side of the DIMM toward the front of the
computer.
Notice that there are two notches in the contact edge of the DIMM module.
2.
Lower the DIMM squarely into the slot so that the notches line up with the
raised key areas of the DIMM socket.
For Technical Support, Call 1-800-708-6227
notches
keys
Upgrading Your Computer
PowerWave 604 UserÕs Guide
chip side
contacts
