3.
Remove the metal cover from the slot you want to use.
Ð If it is a PCI slot, remove the screw holding at the top of the slot and put it somewhere
Ð If it is a NuBus slot, simply slide the cover out and away from the back panel.
4.
Remove the card from its static-proof bag.
Hold the card by its edges and its metal bracket to avoid touching components.
5.
Align the card over the slot.
Hold the card just above the riser card to make sure that you are trying to install a PCI
card into a PCI slot or a NuBus card into a NuBus slot.
Make sure that
Ð the connector on the bottom of the card lines up with the socket on the riser card
Ð the card bracket lines up with the slot on the back panel.
6.
Push the card into the slot until it is Þrmly seated.
Do not force the card. If you feel a lot of resistance, pull the card out, realign it, and
insert it again.
For Technical Support, Call 1-800-708-6227
you will Þnd it.
Pull the cover toward you so that the tongue at the bottom of the cover slides out of
the slot in the chassis.
PCI Slot
Upgrading Your Computer
NuBus Slot
PowerWave 604 UserÕs Guide
23
