Quad Scan Pro
The Quad Scan Pro comes with 4 replaceable gobos. This gobos can
be interchanged at any time and allows you to customize your sys-
tem.
To replace gobo;
1. Select the gobo you would like to replace and unscrew the thumb
screw that is holding the gobo housing in place. Note: The thumb
screw cannot be removed.
2. Remove the gobo housing.
3. Once the gobo housing has been removed, remove the retaining
ring that holds the gobo in. This can easily be done using needle
nose pliers.
4. Remove and replace the gobo with your desired replacement.
Reinsert the retainer ring, and make sure the ring rests firmly
against the gobo.
5. Slide the gobo houseing back into place, and secure the housing
by tighting the thumb screw.
Quad Scan Pro
With this feature you can connect the fixtures to one another
using the IEC input and output sockets. The quantity that can be
connected is 4 fixtures maximum. After 4 fixtures you will need
to use a new power outlet. They must be the same fixtures. DO
NOT mix fixtures.
ADJ Products, LLC - www.adj.com - Quad Scan Pro Instruction Manual Page 22
Gobo Replacement
Power Cord Daisy Chain
Quad Scan Pro
Disconnect the unit from its power source. Remove the power cord
from the unit. Once the cord has been removed, you will find that
the fuse holder is located inside the power socket. Insert a flat-head
screw driver into the power socket and gently pry out the fuse holder.
Remove the bad fuse and replace with a new one. The fuse holder also
has a holder for a spare fuse.
Quad Scan Pro
Fixture Cleaning:
Due to fog residue, smoke, and dust cleaning
the internal and external optical lenses and mirror should be carried
out periodically to optimize light output. Cleaning frequency depends
on the environment in which the fixture operates (I.e. smoke, fog
residue, dust, dew). In heavy club use we recommend cleaning on a
monthly basis. Periodic cleaning will ensure longevity, and crisp out-
put.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics and mirror with glass cleaner and a soft
cloth every 20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
Quad Scan Pro
Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.
No light output from the unit;
1. Be sure the external fuse has not blown. The fuse is located on
the rear panel of the unit.
2. Be sure the fuse holder is completely and properly seated.
Unit does not respond to sound;
1. Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.
ADJ Products, LLC - www.adj.com - Quad Scan Pro Instruction Manual Page 23
Fuse Replacement
Cleaning
Trouble Shooting
