12P Hex/12P Hex Pearl
the fixture will go into when the DMX signal is lost. You can also set this
as the operating mode you would like the unit to return to when power
is applied.
1. Press the MODE button until the DMX address is displayed. Press
the ENTER button until either "Soun", "HOLd", or "blC" is dis-
played.
2. Use the UP or DOWN buttons to find the mode you want incase
of power loss or DMX loss.
• "blC" (Blackout) - If the DMX signal is lost or interrupted, the unit will
automatically go into stand by mode.
• "HOLd" (Last State) - If the DMX signal is lost or interrupted, the fix-
ture will stay in the last DMX set up. If power is applied and this mode
is set, the unit will automatically go into the last DMX set up.
• "Soun" (Sound Active) - If the DMX signal is lost or interrupted, the
unit will automatically go into sound active mode.
3. Find your desired setting and press ENTER. Your setting will be
saved automatically.
ADJ Products, LLC - www.adj.com - 12P Hex/12P Hex Pearl User Manual Page 10
Operating Instructions 12P Hex/12P Hex Pearl
Master-Slave Configuration:
This function will allows you to link units together to run in a Master-
Slave mode. In Master-Slave operation one unit will act as the con-
trolling unit and the others will react to the controlling units built-in
programs. Any unit can act as a Master or as a Slave however, only
one unit can be programmed to act as the "Master."
Master-Slave Connections and Settings:
1. Daisy chain your units via the XLR connector on the rear of the
unit. Use standard XLR data cables to link your units together.
Remember that the Male XLR connector is the input and the
Female XLR connector is the ouput. The first unit in the chain
(master) will use the female XLR connector only. The last unit in
the chain will use the male XLR connector only.
2. Set the "Master" unit to your desired mode of operation.
3. Connect the first "Slave" unit to the "Master."
4. On the "Slave" unit press the MODE button until "SLAv" is dis-
played. The "Slave" unit will now follow the "Master".
12P Hex/12P Hex Pearl
With this feature you can connect the fixtures to one another
using the I.E.C input and output sockets. The quantity that can
be connected is 6 fixtures maximum for 120V and 13 fixtures
maximum for 240V. After the maximum fixtures has been reached
you will need to use a new power outlet. They must be the same
fixtures. DO NOT mix fixtures.
ADJ Products, LLC - www.adj.com - 12P Hex/12P Hex Pearl User Manual Page 11
Master-Slave Configuration

Power Cord Daisy Chain
