Summary of Contents for ADJ MIRAGE Q6 PAK

  • Page 1 MIRAGE Q6 PAK User Manual...
  • Page 2 Products, LLC brands and product names are trademarks or registered trademarks of their respective companies. ADJ Products, LLC and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic...

  • Page 3: Table Of Contents

    System Menu DMX Traits Color Macros Color Temperature Dimmer Curves Cleaning & Maintenance | Daisy Chain Power Linkage Torque Settings Fuse Replacement | Battery Life Dimensional Drawings Specifications ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 3...

  • Page 4: General Information

    GENERAL INFORMATION Introduction: Congratulations on your purchase of the ADJ Mirage Q6 Pak! This package includes 6 ADJ Mirage Q IP battery-operated, IP65-rated, RGBA LED chrome uplights, plus a charging flight case with storage and charging capacity for these devices. All included devices have been designed to per- form reliably for years when the guidelines in this booklet are followed.

  • Page 5: Key Features | Warranty Returns

    • 15 Degree Beam Angle • 4-touch button OLED display on rear panel • Built-in WiFLY EXR wireless DMX: Up to 2,500 feet (760M) when used with ADJ’s WiFLY EXR Battery Transceiver • 64 built-in Color Macros • Flicker Free Operation •...

  • Page 6: Limited Warranty (Usa Only)

    LIMITED WARRANTY (USA ONLY) A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing defects in material and workmanship for a prescribed period from the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including possessions and territories.

  • Page 7: Safety Guidelines

    C. The flight case or charging devices have been exposed to rain or water. D. The appliance does not appear to operate normally or exhibits a marked change in performance. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 7...

  • Page 8: Overview

    *Note: Charge indicator is red when charging, and green when complete. Charge indicator on the case displays charge status of the entire six-unit set. For individual charge status, please refer to the charge indicator on each individual unit. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 8...
  • Page 9 OVERVIEW LIGHTING FIXTURE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 9...

  • Page 10: Dmx Set Up | Dmx Addressing

    Unit 1 Unit 2 Unit 3 Unit 4 Mode Addr Addr Addr Addr Mode Addr Addr Addr Addr 4-Ch 10-Ch 6-Ch 11-Ch 7-Ch 12-Ch 8-Ch 15-Ch 9-Ch 18-Ch ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 10...

  • Page 11: Installation

    NEVER stand directly below the fixture when rigging, removing, or servicing. Allow approximately 15 minutes for the fixture to cool down before servicing. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 11...
  • Page 12 If you lack these qualifications, do not attempt to perform the installation yourself. Improper installation can result in bodily injury. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 12...
  • Page 13 (1). The kickstand can then be deployed from the underside (2) at various notched increments, allowing a maximum angle of 35 degrees from the vertical axis (3). ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 13...

  • Page 14: In-Case Charging

    3. Place an ADJ Mirage Q IP device in any of the device slots in the flight case. Up to 6 devices can be accommodated. The charge indicator located beside the power ports will illuminate to indicate that your device is charging.

  • Page 15: Control Panel

    SET UP to select the currently displayed option. Then use the UP and DOWN buttons to scroll through the sub-menu options until reaching the desired setting. Press the MODE button at any time to return to the main menu without making any adjustments. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 15...

  • Page 16: System Menu

    All channels go to last manual set- Manual Settings tings when signal is lost Unit runs last set Internal Programs internal program when signal is lost CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 16...
  • Page 17 (Passcode = 011) 10s / 20s / 30s / Alarm Time 40s / 50s / 60s Yes / No Service Passcode = 011 Factory Restore CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 17...
  • Page 18 INFORMATION Charging Time xx Hours Time to full charge Current Life xxx% Remaining life Standard 6 Approx 6 hrs Operation Mode Saver 10 Approx 10 hrs BATTERY ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 18...

  • Page 19: Dmx Traits

    Pulse, effect in sequence 160 - 191 LEDs On 192 - 223 Random strobe effect, slow to fast 224 - 255 LEDs On Dimmer Intensity, 0-100% 000 - 255 ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 19...
  • Page 20 061 - 080 Architectural 081 - 100 Theatre 101 - 120 Stage 2 121 - 140 Dim Speed, fast to slow (0.1s - 10.0s) 141 - 255 Default ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 20...
  • Page 21 011 - 026 Auto Program 1 027 - 043 Auto Program 2 044 - 060 Auto Program 3 061 - 076 Auto Program 4 CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 21...
  • Page 22 Pulse, effect in sequences 160 - 191 LEDs On 192 - 223 Random strobe effect, slow to fast 224 - 255 LEDs On CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 22...
  • Page 23 S. Curve 081 - 255 No Function Refresh Rates 000 - 015 Default 016 - 030 900 Hz 031 - 045 1000 Hz CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 23...
  • Page 24 Pulse, effect in sequences 160 - 191 LEDs On 192 - 223 Random strobe effect, slow to fast 224 - 255 LEDs On CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 24...
  • Page 25 5000 Hz 166 - 180 10,000 Hz 181 - 195 15,000 Hz 196 - 210 20,000 Hz 211 - 225 25,000 Hz 226 - 255 No Function ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 25...
  • Page 26 081 - 100 Theatre 101 - 120 Stage 2 121 - 140 Dim Speed, fast to slow (0.1s - 10.0s) 141 - 255 Default CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 26...
  • Page 27 5000 Hz 166 - 180 10,000 Hz 181 - 195 15,000 Hz 196 - 210 20,000 Hz 211 - 225 25,000 Hz 226 - 255 No Function ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 27...
  • Page 28 127 - 143 Auto Program 8 144 - 160 Auto Program 9 161 - 176 Auto Program 10 177 - 193 Auto Program 11 CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 28...
  • Page 29 061 - 075 1200 Hz 076 - 090 1300 Hz 091 - 105 1400 Hz 106 - 120 1500 Hz 121 - 135 2500 Hz CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 29...
  • Page 30 160 - 191 LEDs On 192 - 223 Random strobe effect, slow to fast 224 - 255 LEDs On Dimmer Intensity, 0-100% 000 - 255 CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 30...
  • Page 31 081 - 100 Theatre 101 - 120 Stage 2 121 - 140 Dim Speed, fast to slow (0.1s - 10.0s) 141 - 255 Default CONTINUED ON NEXT PAGE ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 31...
  • Page 32 5000 Hz 166 - 180 10,000 Hz 181 - 195 15,000 Hz 196 - 210 20,000 Hz 211 - 225 25,000 Hz 226 - 255 No Function ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 32...

  • Page 33: Color Macros

    073-076 209-212 077-080 213-216 081-084 217-220 085-088 221-224 089-092 225-228 093-096 229-232 097-100 233-236 101-104 237-240 105-108 241-244 109-112 245-248 113-116 249-252 117-120 253-255 121-124 125-128 129-132 ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 33...

  • Page 34: Color Temperature

    144 - 159 5300K 160 - 175 5900K 176 - 191 6700K 192 - 207 7500K 208 - 223 8700K 224 - 239 9900K 240 - 255 ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 34...

  • Page 35: Dimmer Curves

    DIMMER CURVES ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 35...

  • Page 36: Cleaning & Maintenance | Daisy Chain Power Linkage

    Regular inspections are recommended to ensure proper function and extended life. There are no user serviceable parts inside this fixture. Please refer all other service issues to an authorized ADJ service technician. Should you need any spare parts, please order genuine parts from an authorized ADJ dealer.

  • Page 37: Torque Settings

    CAUTION! DO NOT OVER TORQUE SCREWS AS THIS CAN CAUSE LEAKAGE ISSUES! TO CONFIRM THE IP65 INTEGRITY AFTER A LAMP REPLACEMENT, TEST THE FIXTURE USING THE ELATION IP TESTER. CONTACT ELATION SERVICE FOR MORE DETAILS. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 37...

  • Page 38: Fuse Replacement | Battery Life

    2. Navigate to Battery > Current Life in the system menu. 3. Press and hold the UP button until the device flashes amber once. The device should now display an accurate battery life reading. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 38...

  • Page 39: Dimensional Drawings

    DIMENSIONAL DRAWINGS Dimensions may not be drawn to scale. ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 39...

  • Page 40: Specifications

    (13 programs, & 1 color/fade combo mode); Static Color mode; and Wireless DMX Control With Wired Digital Communication Network Contact Charging system. 6x Charging bases and power supplies included in flight case ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 40...
  • Page 41 ADJ Products, LLC - www.adj.com - Mirage Q6 Pak User Manual Page 41...
