Quad Scan Pro
ADDR -
DMX Address Setting.
1. Press the either the MENU, UP, or DOWN buttons until "ADDR" is
displayed, press ENTER.
2. The current address will now be displayed and flashing. Press the
UP or DOWN buttons to find your desired address. Press ENTER to
set your desired DMX address.
CHND -
This will let select your desired DMX channel
mode.
1. Press the either the MENU button until "CHND" is displayed, press
ENTER. Either "1CH", "5CH" or "32CH" will be displayed
2. Press the UP or DOWN buttons to find your desired DMX mode
and press ENTER to confim and exit.
SLND -
This will let you set unit as a master or slave in
a master/slave configuration.
1. Press the MENU button until "SLND" is displayed, press ENTER.
Either "MAST", "SL 1" or "SL 2" will be displayed.
2. Press the UP or DOWN buttons until your desired setting is dis-
played, press ENTER to confim.
NOTE: In a Master/Slave configuration you can set one fixture to
Master or Slave 1 (SL 1) and then set the next fixture to Slave 2 (SL
2), in doing this the fixtures will now have contrast movement to each
other.
SHND: SH 0 - SH16
programs). Show mode can be run with sound activity or
without. For show mode to run without sound activity turn
sound activity off.
1. Press the MENU button until "SHND" is displayed, press ENTER.
2. "Sh X" will now be displayed, "X" representing a number between
ADJ Products, LLC - www.adj.com - Quad Scan Pro Instruction Manual Page 10
System Menu
- Show modes 0-16 (Factory
Quad Scan Pro
0-16. Programs 0-16 are factory programs, while Show 0 is random
mode. Press the UP or DOWN buttons to find your desired show and
press the ENTER, then press and hold the MENU button for at least 3
seconds to confirm.
SOUN -
Sound Active mode. This mode will run in con-
junction with show mode.
1. Press the MENU button until "SOUN" is displayed, press ENTER.
2. The display will show either "ON" or "OFF". Press the UP or
DOWN buttons to select "ON" to activate sound active mode, or
"OFF" to deactivate sound active mode.
3. Press the ENTER, and then press and hold the MENU button for at
least 3 seconds to confirm.
SENS -
Sound sensitivity control.
1. Press the MENU button until "SENS" is displayed, press ENTER.
2. The display will show a number between 0-100. Press the UP or
DOWN buttons to adjust the sound sensitivity. 0 being the least sen-
sitive and 100 the most sensitive.
3. Press the ENTER button to confirm.
DNST
- This mode can be used as a precaution mode, that
in case the DMX signal is lost, the operating mode chosen
in the setup is the running mode the fixture will go into when
the DMX signal is lost. You can also set this as the operat-
ing mode you would like the unit to return to when power is
applied.
1. Press the MENU button until "DNST" is displayed, press ENTER.
2. Either "MASL", "BLND", or "LAST" will be displayed. Choose an
operating mode you would like the unit to start up in when power is
applied or the DMX signal is lost.
• MASL (Master Slave) - If the DMX signal is lost or power is applied,
the unit will automatically go into Master Slave mode.
