Show - ADJ QUAD SCAN PRO User Instructions

Quad Scan Pro
Unpacking:
Thank you for purchasing the Quad Scan Pro by ADJ
Products, LLC . Every Quad Scan Pro has been thoroughly tested and
®
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect your fixture for
any damage and be sure all equipment necessary to operate the unit
has arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return this unit to your dealer without
contacting customer support first.
Introduction:
The Quad Scan Pro is a DMX intelligent, RGBW "Quad
Color" LED scanner. The Quad Scan Pro can operate as a stand alone
fixture or in a Master/Slave configuration. The Quad Scan Pro has three
operating modes; sound active mode, show mode, and DMX control.
This fixture is suitable for theaters, studios, retail stores, and other
similar locations. For best results use fog or special effects smoke to
enhance the beams projections.
Customer Support:
ADJ Products, LLC provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Warning!
This may cause severe eye damage. Avoid looking directly
into the light source at all times!
ADJ Products, LLC - www.adj.com - Quad Scan Pro Instruction Manual Page 2
General Information
Quad Scan Pro
To optimize the performance of this product, please read these
operating instructions carefully to familiarize yourself with the basic
operations of this unit. These instructions contain important safety
information regarding the use and maintenance of this unit. Please
keep this manual with the unit, for future reference.
Quad Scan Pro
• DMX-512 Protocol Compatible (1, 5, or 32 DMX Channels)
• X/Y Mirror Control
• 3 Operating Modes - Sound Active, Show Mode, and DMX Control
• Internal Microphone
• Digital Display for Address and Function Setting
• UC3 Controller (Not Included)
• Power Cord Daisy Chaining (See page 22)
Quad Scan Pro
The Quad Scan Pro carries a 2 year (730 days) limited warranty.
Please fill out the enclosed warranty card to validate your purchase
and warranty. You may also register your product online at www.
americandj.com. All returned service items whether under warranty or
not, must be freight pre-paid and accompany a return authorization
(R.A.) number. If the unit is under warranty you must provide a copy
of your proof of purchase invoice. Please contact ADJ customer sup-
port for a R.A. number.
Quad Scan Pro
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact ADJ.
ADJ Products, LLC will not accept any liability for any resulting dam-
ages caused by the non-observance of this manual or any unauthor-
ized modification to this unit.
ADJ Products, LLC - www.adj.com - Quad Scan Pro Instruction Manual Page 3
General Instructions
Features
Warranty Registration
Handling Precautions
