ADJ quad phase User Instruction

User Instructions
Rev. 3/14
American DJ
®
6122 S. Eastern Ave.
Los Angeles CA. 90040
www.americandj.com
Quad Phase
Unpacking:
Thank you for purchasing the Quad Phase by Ameri-
can DJ . Every Quad Phase has been thoroughly tested and has been
®
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your fixture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support first.
Introduction:
The Quad Phase is a four channel, DMX intelligent
LED fixture. The fixture can operate in as a stand alone fixture or in
a Master/Slave configuration. The Quad Phase has two operating
modes; sound active and DMX Control. This fixture is suitable for the-
aters, studios, retail stores, and other similar locations. For best results
use fog or special effects smoke to enhance the beams projections.
Customer Support:
American DJ
support line, to provide help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacific Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2941
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
This may cause eye damage. Avoid looking directly into the
light source. Use sensible precaution.
American DJ - www.americandj.com - Quad Phase Instruction Manual Page 2
®
General Information
provides a toll free customer
®
