Quad Scan Pro
Channel
Value
16
0 - 8
9 - 131
132 - 139
140 - 181
182 - 189
190 - 231
232 - 239
240 - 247
248 - 255
17
0 - 255
18
0 - 255
19
0 - 255
20
0 - 255
21
0 - 255
22
0 - 255
23
0 - 255
24
0 - 8
9 - 131
132 - 139
140 - 181
182 - 189
190 - 231
232 - 239
240 - 247
248 - 255
25
0 - 255
ADJ Products, LLC - www.adj.com - Quad Scan Pro Instruction Manual Page 20
32 Channel Mode - DMX Traits
Function
STROBING (MIRROR 2)
OPEN
STROBING SLOW - FAST
OPEN
FAST CLOSE - SLOW OPEN
OPEN
SLOW CLOSE - FAST OPEN
OPEN
SOUND ACTIVE STROBING
OPEN
MIRROR 3 PAN
MIRROR 3 TILT
RED (MIRROR 3)
0% - 100%
GREEN (MIRROR 3)
0% - 100%
BLUE (MIRROR 3)
0% - 100%
WHITE (MIRROR 3)
0% - 100%
MASTER DIMMER (MIRROR 3)
0% - 100%
STROBING (MIRROR 3)
OPEN
STROBING SLOW - FAST
OPEN
FAST CLOSE - SLOW OPEN
OPEN
SLOW CLOSE - FAST OPEN
OPEN
SOUND ACTIVE STROBING
OPEN
MIRROR 4 PAN
Quad Scan Pro
Channel
Value
26
0 - 255
27
0 - 255
28
0 - 255
29
0 - 255
30
0 - 255
31
0 - 255
32
0 - 8
9 - 131
132 - 139
140 - 181
182 - 189
190 - 231
232 - 239
240 - 247
248 - 255
ADJ Products, LLC - www.adj.com - Quad Scan Pro Instruction Manual Page 21
32 Channel Mode - DMX Traits
Function
MIRROR 4 TILT
RED (MIRROR 4)
0% - 100%
GREEN (MIRROR 4)
0% - 100%
BLUE (MIRROR 4)
0% - 100%
WHITE (MIRROR 4)
0% - 100%
MASTER DIMMER (MIRROR 4)
0% - 100%
STROBING (MIRROR 4)
OPEN
STROBING SLOW - FAST
OPEN
FAST CLOSE - SLOW OPEN
OPEN
SLOW CLOSE - FAST OPEN
OPEN
SOUND ACTIVE STROBING
OPEN
