Advanced System Operation
7.
Transmitters
The Transmitters menu offers two utilities, TX List and TX Test.
The TX List comprises all registered transmitters and their last reported status.
To view the TX list:
1. From the Service menu, select Transmitters, TX List [7071]; the first
transmitter on the list is displayed.
2. Using the arrow buttons, scroll through the transmitter list.
3. When you have finished viewing, press
The TX list and TX test display the following information on each transmitter:
Status
OK
TA
BT
OS
NA
Press The left SOS button
The second utility, TX Test enables you to identify transmitters.
In TX Test mode, each time a transmission is received, a chime is sounded and the
activated transmitter's details are displayed.
To initiate TX Test mode:
1. From the Service menu, select Transmitters, TX Test [7072].
2. Activate a transmitter; the transmitter's details are displayed.
3. When you have finished, press
CommPact User Manual
Meaning
The transmitter is functioning correctly
Tamper condition
Battery low
The transmitter is out of
synchronization
The transmitter is inactive
to display the transmitter's default descriptor.
to exit TX Test mode.
to exit the list.
Notify
your
engineer
