The User Interface
2.
Setting Keys
Three setting keys are available: Full, Part and Perimeter. These keys set the system
using one of the three setting methods. One-key Setting is an option that is programmed
by your engineer. If this option is disabled, you must also enter a user code when
setting.
Panic Alarm
Simultaneously pressing the Full and Perimeter buttons generates a panic alarm.
Cancel
The Cancel key clears the keypad in the event that you pressed a key by mistake.
For example, when entering your code you enter a wrong digit; the system waits for you
to enter all four digits before it decides that the code is incorrect. Pressing the Cancel key
causes the keypad to disregard what was previously entered enabling you to start again.
Battery Status LEDs
Every time a key is pressed, one of the Battery Status LEDs is lit. When the battery needs
to be replaced, the red Low Battery LED is lit.
9
