Electrical Connections

Please ensure the following are available and have been tested prior to the installation:
• Mains point
• Network point
• Network cable
• Active video signals i.e. at least one working camera feed
• PC with CD ROM drive and connection to the same network as the DVR
(Recommended).

Quick Overview of SD Advanced Record Settings

The SD Advanced provides as default:
High performance recording on ALL cameras with minimal configuration.
Consistent recording duration and smooth motion video per camera regardless of the number of
cameras.
Default record settings at MPEG4 6pps (at 2CIF), JPEG 3pps (at 2CIF) and MultiMode recording at
MPEG4 6pps (at 2CIF), JPEG 6pps (at 2CIF).
Pre-configured up to 14, 30, 45, 60 or 90 days storage settings (dependant on model).

Complete Flexibility

The advanced record menu can be used to configure individual cameras to suit specific
requirements e.g. Entry/Exit routes. Various storage sizes are available dependant on the
combination of the number of cameras, the storage options and record rates selected.
Note: It is the Installer/Owner's responsibility to ensure that the record duration is set to the
necessary requirements of the application.
Recording
MultiMode
The unit supports MultiMode recording, which is a storage technology developed by Dedicated
Micros. This offers the ability to set different recording rates, resolutions and compression formats
across scheduled, normal and alarm modes for each individual camera.
By varying the quality, bit rate and file size of the recorded images, the MultiMode function can
increase recording capabilities of the unit.
MultiMode offers:
Ability to set different recording resolutions.
Ability to set and switch MPEG or JPEG compression recording as required.
Ability to set PPS recording rate per camera.
Dynamically switchable resolution when switching from Normal to Event recording.
Dynamically switchable compression between MPEG4 and JPEG from Normal to
Event recording.
