Unit Operation
The unit can be operated via the Viewer menus and the enclosed IR Remote Control, the optional
keyboard or with a USB mouse. They can also be viewed and accessed remotely via the webpages
and the 'Viewer' menu option.
Operating the Viewer
Navigation is via a colour coded softkey system. The coloured menu provides an intuitive approach
to operator and installer use. The coloured keys on the IR Remote Control correspond to the menu
options displayed on screen.
Note: The screen images shown throughout this section are those displayed on a local monitor. If
viewing remotely via the webpages, the menu layout will differ slightly.
The function of the keys will change according to whether the unit is in Live or Playback mode.
Overleaf are described the available Viewer menu pages. To display the colour coded menu
options, press the OK button on the IR Remote Control or click the mouse button.
110
Dedicated Micros ©2009
