Telem UDP Port Selection
Telemetry Port
User Logging
Comb Filter
Auto Update Web Variables
Disable Transcoding
Enable External Modules

Select 'Automatic' to enable the unit to select a suitable port for
telemetry purposes.
Select 'Default' to use the default port settings (1025).
Select 'User Defined' to use settings entered in the 'Telemetry
Port' option.
Enter the port settings for telemetry data here. The default setting
is 1025.
Enable this option to activate User Logging. Refer to 'Appendix C'
for further information regarding the User Logging function.
Enable this option to activate the Comb Filter function. Comb
Filter can help improve the fine details of a video signal image by
filtering the luminance and chrominance separation process.
Configures the unit to update all system variables required for an
automatic upgrade without requiring confirmation. Do not check
this box if you run a customised applet.
Select to disable the unit's transcoding capabilities. In normal
circumstances this should always remain enabled, however it can
be useful to disable the feature when conducting maintenance.
Select to enable any connected RS485 alarm modules.
