Alarm Settings

The Alarm Settings menus allow configuration of the unit's alarm functionality. Individual alarm inputs
and alarm zones can be configured. Global relays can be activated and the Activity grid set up.
Refer to the individual menus for further details.
The Alarm Input page allows configuration of alarm channels. Up to 20 alarm channels are available.
The Zone Input page enables the configuration of alarm zones. Up to 32 separate alarm zones can
be created.
The Zone Actions page enables actions such as Go to Preset or Archiving to be allocated to alarm
zones. Zones can also be associated with a specific camera. On receipt of an alarm, images from
the associated (primary) camera will automatically be displayed in the Viewer menu.
The VMD/Activity Response page enables configuration of responses following an VMD/Activity
Detection trigger.
The Activity Setup page allowed activation and configuration of the Activity feature on all video
inputs. The Activity feature enables cameras to automatically detect any movement/changes within
the video scene. This can trigger a number of operations such as FTP alarm notification or an
increase in the recording rate.
The VMD Configuration page enables the unit's VMD (Video Motion Detection) to be set-up. VMD
allows a camera to automatically detect if there is any movement/changes within specific areas of
the video scene.
The Global Relays page allows the four onboard relay connections and global relay settings to be
configured.
