FIGURE 18.
Page 26
5.1.5 Front End Detail
Front End Detail
1.00
Image Plane
CCD Imager
1.41
18.20
Front End
C-Mount Ring
16.8
TM-7200/TM-6200 High Resolution Digital CCD Camera
