Nexcom PEAK 715-HT Series User Manual page 65

J 20 : IR Connector
PIN No.
1
2
3
4
5
J 9 : SMBUS Connector
PIN No. Description
1 SMBDATA
2
J 11 : Hardware Reset
PIN No. Description
1
2
Description
VCC5
CIRRX
IRRX
GND
IRTX
SMBCLK
GND
Reset #
J 23 : External Keyboard Connector
PIN No.
1
2
3
4
5
J 8 : ATX Push Button
PIN No.
1
2
J 16 : ATX Power Connector
PIN No.
1
2
3
64
Description
Keyclk
Keydata
N.C
GND
VCC5
Description
GND
Plus Signal
Description
5VSBY
GND
PSON #
