Refer to your drive's documentation or look on the drive if you need to obtain this
information. If no device is installed, change the value to None.
Access Mode
This item defines some special ways that can be used to access IDE hard disks
such as LBA (Logical Block Addressing). Leave this value at Auto and the system
will automatically decide the fastest way to access the hard disk drive.
Press <Esc> to close the IDE device submenu and return to the Standard CMOS
Features page.
Floppy Drive A and Floppy Drive B
Options for these fields are:
None
360K, 5.25 in
1.2M, 5.25 in
720K, 3.5 in
1.44M, 3.5 in
2.88M, 3.5 in
The None option could be used for diskless workstations.
Floppy 3 Mode Support
Floppy 3 mode refers to a 3.5" diskette with a capacity of 1.2 MB. This mode
is sometimes used in Japan.
Video
Set this field to the type of graphics card installed in your system. If you are using
a VGA or higher resolution card, choose the EGA/VGA option. The options are:
EGA/VGA Enhanced Graphics Adapter/Video Graphics Array. For EGA, VGA,
SEGA, or PGA monitor adapters.
CGA 40 Color Graphics Adapter, power up in 40 column mode
CGA 80 Color Graphics Adapter, power up in 40 column mode
Mono Monochrome adapter, includes high resolution monochrome
adapters
No floppy drive installed
5-1/4 inch PC-type standard drive; 360 kilobyte capacity
5-1/4 inch AT-type high-density drive; 1.2 megabyte capacity
3-1/2 inch double-sided drive; 720 kilobyte capacity
3-1/2 inch double-sided drive; 1.44 megabyte capacity
3-1/2 inch double-sided drive; 2.88 megabyte capacity
