4.4 Standard CMOS Features

Selecting Standard CMOS Features on the main program screen displays the
following menu:
The Standard CMOS Setup utility is used to configure the following features:
Date
The date format is <week>, <month>, <day>, <year>.
Day
Month
Date
Year
Time
The times format in <hour> <minute> <second>. The time is calculated base on the
24-hour military-time clock. For example, 1 p.m. is 13:00:00.
IDE Devices
Your computer has two IDE channels (Primary and Secondary) and each channel can
be installed with one or two devices (Master and Slave). Use these items to configure
each device on the IDE channel. Press <Enter> to display the IDE submenu:

Figure 4-2 : BIOS- Standard CMOS Features

The week, from Sun to Sat, determined by the BIOS and is display only
The month, Jan. through Dec.
The day, from 1 to 31 (or the maximum allowed in the month)
The year, depend on the year of BIOS
