Installation and Operation Guide
1.4
Physical Description
The CGW-D device controls and connectors on the front panel are displayed in Figure 1-1. The SIM
insertion port on the bottom panel is displayed in Figure 1-2.
1-2
Antenna Connector
LCD Display
USB Connector
FXO/PSTN Connector
FXS/Phone Connector
Power Connector
Figure 1-1. CGW-D Controls and Connectors
Figure 1-2. SIM Insertion Port
