3.1

Overview

This chapter displays all the system windows and details the function of all controls and fields.
3.2

Main Screen Structure

The CGW-D application is based on a tabbed pane that contains four menus (detailed in
Paragraph 3.2.1) and four tabs (detailed in 3.2.2).

3.2.1 Application Menus

The CGW-D application has the following menus:
File menu (see Paragraph 3.2.1.1).
Communication menu (see Paragraph 3.2.1.2).
Tools menu (see Paragraph 3.2.1.3).
Help menu (see Paragraph 3.2.1.4).

3.2.1.1 File Menu

The File menu (Figure 3-1) serves for standard operations as customary in most Windows-based
applications.

Chapter 3: User Interface

3.
Figure 3-1. File Menu
CGW-D
3-1
