2.2. CGW-I Physical Description
Your device is housed in secure metal box, of which the height is 215mm,
depth 125mm and width 42mm.
Figure 2-1: Front View of the CGW-I Box
SIM 1 Slot
SIM 2 Slot
Figure 2-2: Bottom View of the CGW-I Box
CGW-I Cellular Gateway BRI-GSM : Installation and Operation Manual
Antenna Connectors
Liquid Crystal Display
LAN (LI & ACT) Indicators
LAN Connector
RS-232 Connector
Cellular Engine Indicators
ISDN Connector
Sync-In Connector
Power Supply Connector
5
