Installation and Operation Guide
1.4
Physical Description
The front panel controls and connectors of the CGW-D device are displayed in Figure 1-1. The SIM
insertion port on the bottom panel is displayed in Figure 1-2.
1-2
Antenna Connector
L CD Display
US B Connector
F XO/P S T N Connector
F X S /P hone Connector
P ower Connector
Figure 1-1. CGW-D Controls and Connectors
Figure 1-2. SIM Insertion Port
