4.1

Overview

This chapter provides programming instructions for the administrator.
4.2

CGW-D Start-Up and Idle Modes

To initialize the device and set it to idle mode, perform the steps as follows:
a. Connect the supplied antenna to the Ant. socket.
b. Connect the required cables to the To PSTN and/or To PBX sockets (see Home Configuration
connection diagram in Chapter 1).
c. Insert SIM card to the SIM card port on the bottom panel.
d. Connect the external power supply to the power connector. The LCD display lights up and
displays the initialization message (Figure 4-1), followed by idle mode message (Figure 4-2).

Chapter 4: Programming Guide

v2 = Software version
CGWD v2 [INIT-N]
G S M
N = 9 to 0 countdown
Figure 4-1. Start-Up Mode
XX = Radio signal reception level
CGWD v2 [-XX]
YY....Y
YY....Y = Cellular operator name
Figure 4-2. Idle Mode
The minimum recommended reception level is -80 dB.
4.
CGW-D
4-1
