- Page 1 CelluLine CGW-TS GSM Cellular Gateway Installation and Programming Manual...
- Page 3 CelluLine CGW-TS – GSM Cellular Gateway Installation and Programming Manual CGWTS-M001A Version 1, Release 1, December 2004...
- Page 4 The following shall void the above warranty: malfunctions resulting from fire, accident, neglect, abuse, or acts of God; use of improper electrical power; or repair of, tampering with or alteration of the product by anyone other than ITS authorized personnel. Copyright 2004 © ITS Telecom...
-
Page 5: Table Of Contents
Inserting the SIM Card..........6 Installing the CGW-TS ..........6 LED Status Indicators and Diagnostics....9 LED Activity Status Indicators ........10 LED Error Status Indicators........11 Diagnostics...............13 Antenna ..............14 DTMF Programming ..........15 DTMF Programming Commands ......16 Technical Data ............21 CelluLine CGW-TS: Installation and Programming Manual... -
Page 7: Introduction
1 Introduction Your new ITS CelluLine CGW-TS is a cellular gateway that connects your PBX (Private Branch eXchange) directly to a GSM network, bypassing the landline carrier. By routing your outgoing calls made to cellular numbers through your new CGW-TS, you will be able to eliminate excessive interconnection fees charged by the landline carrier, thus cutting your telephone costs significantly. -
Page 8: Main Features
Prefix blocking (up to 10) Conversation time-out Reverse polarity signaling support Audio volume control • Supports DTMF dialing • Line interface, 2-wire (RJ-11 connector) • Plug & Play installation • High quality audio • Maintenance free CelluLine CGW-TS: Installation and Programming Manual... -
Page 9: Physical Description
Status LED (Red) • 4 Received Signal Level LEDs (Yellow) The Bottom to the CGW-TS contains: • Antenna connector • Trunk interface connector • Power Supply connector • SIM release lever • SIM card tray CelluLine CGW-TS: Installation and Programming Manual... -
Page 11: Installation
GSM mobile phone, or bring it to your local GSM Service Center. Before you install the SIM card, disable all Call Forwarding modes (in the event of busy signal, absence, unavailability, etc.) and Call Waiting from the GSM operator. CelluLine CGW-TS: Installation and Programming Manual... -
Page 12: Inserting The Sim Card
The LEDs indicate the level of GSM reception. The signal strength is updated every 15 seconds. Experiment to find the strongest signal. For more tips on where to place the antenna, see page 14. CelluLine CGW-TS: Installation and Programming Manual... - Page 13 Connect the supplied 9V DC adaptor to the unit. Plug it in the power supply. The CGW-TS will begin initialization and registration. At the end of the process, the LEDs will display the GSM signal status. For details on programming the CGW-TS, see Chapter 4. CelluLine CGW-TS: Installation and Programming Manual...
-
Page 15: Led Status Indicators And Diagnostics
RJ-11 connector to the trunk connector in the unit. For details on how to perform further diagnostics, see page 13. Note that LED 1 is located at the bottom of the Signal Level column and LED 4 is located at the top. CelluLine CGW-TS: Installation and Programming Manual... -
Page 16: Led Activity Status Indicators
LED Activity Status Indicators LED Status Indicators Description LED1 LED2 LED3 LED4 Power Status Yellow Yellow Yellow Yellow Green Standby Mode Conversation Flashing fast Incoming Call Flashing fast Outgoing Call Flashing fast Programming Flashing Mode CelluLine CGW-TS: Installation and Programming Manual... -
Page 17: Led Error Status Indicators
Check your antenna connection or move your antenna to a location with a better reception or enable your roaming parameter (See Diagnostics) Registration Flashing Flashing denied Solution Contact your local GSM operator or enable your roaming parameter (See Diagnostics) CelluLine CGW-TS: Installation and Programming Manual... - Page 18 SIM card is not Flashing readable Solution Check the SIM position or replace the SIM card or contact your local operator No SIM card Flashing inserted Solution Insert the SIM card CelluLine CGW-TS: Installation and Programming Manual...
-
Page 19: Diagnostics
SIM card with your original SIM card. Note that all cellular calls you now make from your CGW-TS will be routed through the alternate GSM network that you used to complete your registration. CelluLine CGW-TS: Installation and Programming Manual... -
Page 20: Antenna
PBX. • Verify that the distance between the antenna and any surrounding antennas is at least 35 cm. • Position the antenna vertically and pointing upwards. CelluLine CGW-TS: Installation and Programming Manual... -
Page 21: Dtmf Programming
Programming mode. • When you enter an incorrect command, the CGW-TS will “beep” an alert one time. • When you enter a correct command, the CGW-TS will “beep” an alert two times. CelluLine CGW-TS: Installation and Programming Manual... -
Page 22: Dtmf Programming Commands
(default) before the dialing length. starts If you enter exactly XX digits, the CGW-TS immediately dials the number If you enter more than XX digits, the CGW-TS will cut off the number after it reaches XX. CelluLine CGW-TS: Installation and Programming Manual... - Page 23 Control parameter, the louder the audio will be. Conversation Time-Out *390 + XX 00 (unlimited) where: The telephone conversation will be XX = number of minutes automatically terminated after this 00 = unlimited time-out. CelluLine CGW-TS: Installation and Programming Manual...
- Page 24 When roaming is ON, the CGW-TS X = 0, off can register with another GSM X = 1, on operator. When roaming is OFF, the CGW-TS can only register with the predefined GSM operator. CelluLine CGW-TS: Installation and Programming Manual...
- Page 25 When the parameter is 1 (ON), the number will not be shown. Change Programming Password *600 + new password 1234 where: password must be 4 digits (only digits 0-9) Reset Unit with Default Values *151 CelluLine CGW-TS: Installation and Programming Manual...
-
Page 27: Technical Data
To analog trunk interface of PBX – RJ-11 (Trunk) (operational mode) To analog telephone – RJ-11 (Trunk) Power Supply Antenna – SMA Female Off-hook AC Impedance 600Ω On-hook Line Voltage 48VDC Off-hook Line Current Maximum 25mA CelluLine CGW-TS: Installation and Programming Manual... - Page 28 50Ω Impedance, connected via SMA connector Frequency 800-1900MHz–2.5dB Antenna Cable Length 3m (9.8ft) Power Supply Input: 110VAC, 60Hz 220VAC, 50Hz Output: 9VDC, 800mA Temperature Range 0˚C-45˚C 32˚F-113˚F Maximum Relative Humidity Dimensions (HxWxD) 160x145x30mm / 6.3x5.7x1.2inch CelluLine CGW-TS: Installation and Programming Manual...
- Page 30 29 Hametzuda Street 58001 Azur, Israel Tel: +972-3-5576866 Fax: +972-3-5576942 www.its-tel.com Eits@its-tel.com Control#: CGWTS-M001A...
