1.5

Getting Started

Getting started with the CGW-D comprises the following stages:
Preparation to operation:
Connecting the device to 9 VDC power using the supplied adaptor.
Installing the supplied GUI software on a PC (refer to Chapter 2 for instructions).
Installing USB drivers (refer to Chapter 2 for instructions).
Connecting the device to PC via the USB interface.
Programming the device as required.
Device installation:
Connecting the antenna to the antenna connector.
Inserting a SIM card into the port.
Connecting the device in one of the following configurations, according to its purpose:
Private use at home (Figure 1-3).
Office trunk use (Figure 1-4).
Office trunk gateway (Figure 1-5).
Office extension use (Figure 1-6 or Figure 1-7).
Make sure not to connect the PSTN line to the phone (FXS) socket! This connection may
harm your FXS interface hardware.
