g. Enter password (default: 1234). If all parameters were successfully completed, the message Apply
parameters completed appears on the screen.
h. To test the function, lift the home phone receiver. The device displays a message (Figure 4-5).
i. Dial a cellular number beginning with the permitted prefix. The number appears on display
(Figure 4-6), and the device notifies by two short beeps that the call is routed to a cellular
network.
j. When the person at the destination answers and the call is in progress, the device displays a
message (Figure 4-7).
Figure 4-7. Call in Progress With Permitted Prefix
k. Disconnect the call.
l. Dial a cellular or PSTN number that does not contain a permitted prefix. The call is routed to the
PSTN network, and a message is displayed (Figure 4-8).
Please dial...
Figure 4-5. Message Before Dialing
Please dial...
9167798654
Figure 4-6. Dialed Cellular Number
<Call Connected>
[Phone -> GSM]
<Call Connected>
[Phone -> PSTN]
Figure 4-8. Call Routed to PSTN
