Camera Connection
Basic Connection (Without PoE)
Connect the power adaptor to camera device.
Connect the camera to the Ethernet hub via RJ45 Ethernet cable.
Power over Ethernet (PoE) Connection
Connect the camera to a PoE-enabled hub via single Ethernet cable.
Connect the camera to a non-PoE hub via PoE Injector.
12
12
