Technical Specifications - Brickcom FD-100A Series User Manual

Technical specifications

Product Name
Model Number
Hardware System
Image Sensor
Infrared LEDs
Lens
Video
Image Resolution
and Frame Rate:
Audio
Communication
Pan/Tilt
Interface & Buttons
General Specification
Megapixel Day & Night Fixed Dome Network Camera
FD-100A
CPU: 500 MHz
Flash: 16M
RAM: 64M DDR
Sensor Type : 1/4" Mega-Pixel CMOS Sensor
Sensor Resolution : 1280 x 800 pixel
Minimum Illumination :
1 Lux (without IR LEDs)
0 Lux (IR LEDs ON)
Triggered by Auto Light Sensor
Lens Type : Board Lens
Focal Length: f= 3.3mm~12mm
View Angle : H: 17.9° ~ 63.6°
V:13.5° ~ 46.5°
Image Compression : H.264 / MPEG4 / MJPEG /
Auto Exposure Control / Auto White Balance / Auto Gain Control
- 1280 x 800: 30fps
- 640 x 400: 30fps
External MIC input
External speaker output
Ethernet : one 10/100Mbps RJ-45
Supported Protocols : TCP/IP, UDP, ICMP, DHCP, NTP, DNS,
DDNS, SMTP, FTP, HTTP, Samba, PPPoE, UPnP, RTP, RTSP,
RTCP
Manual 3-axis
DC Power Connector
Ethernet Cable Connector
General I/O Terminal block
External MIC input
External speaker output
124
