- Page 1 Easy Installation Guide Megapixel Day & Night Fixed Box Network Camera FB-Series English...
-
Page 2: Power Adapter (Optional)
Step 1. Check Package Contents a. Network Camera b. CS mount Lens (Optional) (W)FB-300Np V5 & FB-500/300/200 Series FB-H Series c. Product CD d. Camera Stand e. Warranty Card f. A/V Cable 【(W)FB-300N V5 series Cable Are Optional】 g. Power Adapter (Optional) h. - Page 3 i. Allen Key j. Detachable Antenna (Optional)
- Page 4 Step 2.Hardware Installation Mounting the CS-Mount Lens to the Camera <Vari-focal Lens with Manual Iris> --- Optional Lens Connect the CS-mount lens to the camera by turning it clockwise onto the camera mount until it stops. If necessary, adjust the iris controller, focus controller, and zoom controller to get the best resolution. To adjust the lens: Adjust the iris ring controller to control the amount of light coming through the lens.
- Page 5 <Vari-focal Lens with Auto Iris> --- Optional Lens Connect the CS-mount lens to the camera by turning it clockwise onto the camera mount until it stops. If necessary, adjust focus controller, and zoom controller to get the best resolution. Connect the lens cable plug (DC Iris control cable) to the camera side connector 【FB-500/300/200 Series】...
- Page 6 **Connect a Monitor to the Camera: (This only apply for FB-500A /(W)FB-300N /FB-H200N series)** Use an A/V Cable to view the camera’s video feed and manually adjust the lens iris, focus, and zoom to get the desired image quality. Connect the A/V Cable to the monitor. 【(W)FB-300Np V5 &...
- Page 7 Depending on the user’s application, an Ethernet cable may be needed. The Ethernet cable should meet the specs of UTP Category 5 and not exceed 100 meters in length. When powering up, the power LED will light up and the camera will boot up. The link LED will be an illuminate as amber when obtaining the IP address.
- Page 8 1. Use a standard RJ-45 cable to connect the camera to a PoE Injector. 2. Use a standard RJ-45 cable to connect the PoE Injector to the non-PoE switch. 3. Use a standard power cable to connect the PoE Injector to a power outlet. Complete the Installation Step 4.Install the EasyConfig Software Insert the CD into the CD-ROM, and follow the instructions of the InstallShield Wizard to finish...
