- Page 1 Easy Installation Guide Megapixel Day & Night Fixed Dome Network Camera Fixed Dome Series English...
- Page 2 Step 1. Check Package Contents a. Network Camera b. Terminal Block (Fixed Dome series) c. Product CD d. Location Sticker e. Warranty Card Screw bag g. Easy Installation Guide h. L-WM-01(Optional)
- Page 3 Step 2 .Hardware Installation WARNING - Do not mount the camera on a soft material. The camera may fall and be damaged. This document is for easy installation purpose only; please refer to the user manual for more details. 1. Remove the dome cover from the camera device. I.
- Page 4 ll. For SD/SDHC card (*) installation: For wall installation: Chose the location on the wall to place the camera. Attach the location sticker to the desired spot. Drill four holes through the center of the four location holes on the sticker. Hammer the four plastic anchors which are provided in the product package into the four location holes.
- Page 5 Mount the camera on the wall and position to four screw slots over the plastic anchors. Insert the screws into the holes and use the screwdriver to tighten the screws clockwise until they are secure. Place the dome cover back on the camera device. 3.
- Page 6 4. Adjust the Lens Focus Range and Zoom Viewing (This Function is only apply for FD-300Ap) How to adjust the Lens angle? Release the pan screw and then rotate the lens to left or right. After completion, tighten the pan screw.
- Page 7 How to adjust the view angle and focus range Release the view angle controller and then moving the controller bar left or right to adjust the view angle. After completion, tighten the view angle controller. Release the focus controller and then moving the controller bar left or right to adjust the focus range.
- Page 8 Step 3.Install Camera and Network Devices Basic Connection (Without PoE) Connect the power adaptor to the camera device. Connect the camera to the Ethernet hub using a RJ45 Ethernet cable. Power over Ethernet (PoE) Connection Connect the camera to a PoE-enabled hub via single Ethernet cable. Connect the camera to a non-PoE hub via PoE Injector.
- Page 9 Step 4.Install the EasyConfig Software Insert the CD into the CD-ROM, and follow the instructions of the InstallShield Wizard to finish installation. Step 5.Launch EasyConfig Launch the EasyConfig software, and click on the camera from the survey list to connect. Follow the EasyConfig software to configure the camera’s IP address and EasyLink settings.
