2-3 Connectors

Jumper/Connector Define
J1: External speaker connector
Pin 1
Speaker signal
J2: Power supply type select:
Pin1-2 short
Pin2-3 short
J4: 5VSB power cable connector
Pin 1
5VSB
Jp1: VCC5 power connector (for DOM)
Pin 1
VCC5
Jp3: Keylock connector
Pin 1
VCC5
J13: Reset button
Pin 1-2
JP4: CMOS set up
Pin 1-2
Normal
J9: Power On button (ATX)
Pin 1-2
J11: IDE LED connector
Pin 1
VCC5
Capability Expand
Pin 2, 3
GND
AT power
ATX power
Pin 2
GND
Pin 2
GND
Pin 3,5
GND
Reset
Pin 2-3
Clear CMOS
Power on
Pin 2
IDE LED signal
Rev. A
Pin4
VCC5
Pin3
ATX power supply S_ON"
Pin 4
keylock signal
October 2000
2-3
