Peak 650 User's Guide
1,2,4  4 seconds time-out intervals
!
Dimensions
!
340mm(L) × 122mm(W)
!
! Power Requirements
TBD for ( Max. Typical )
!
! Environments
Operating temperatures0°C to 60°C
!
Storage temperatures-20°C to 80°C
!
Relative humidity10% to 90% (Non-condensing)
!
! Certification
CE Verification
!
FCC Class A
!
! Model Available
PEAK 650VL2 -- Full-size Socket 370 Celeron/Pentium III CPU card w/VGA/Dual LAN
!
PEAK 650M8 –Full-size Socket 370 Celeron/Pentium III CPU card w/ATI M4 VGA w8MB /LANWhat
!
you'll have from the package
!
In addition to this manual, the PEAK 650 package includes the following items
PEAK 650 Board
Cable Set, include UDMA66 IDE Cable x 1; FDD
Cable x1 ; Internal Keyboard Connector x1 ;
COM and LPT Cable w/Bracket
Y CABLE PS/2 1 TO 2 KEYBOARD/MOUSE
ATX Power Cable connect SBC and BackPlane
Driver CD
PEAK 650 Quick Reference Guide Rev.A
If any of these items is missed or damaged, please contact your vendor for what you want
Introduction
Items
Rev. A
650VL2 650M8
1 1
1 1
1 1
1 1
1 1
1 1
October 2000
1-5
