  • Page 1 ACP-2010MB 2U-High Rackmount Chassis for ATX / MicroATX Motherboard User Manual...
  • Page 2 No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reli- able.

  • Page 3: Safety Instructions

    Safety Instructions Read these safety instructions carefully Keep this user manual for later reference. Disconnect this equipment from AC outlet before cleaning. Do not use liquid or spray detergents for cleaning. For pluggable equipment, the power outlet shall be installed near the equipment and shall be easily accessible.
  • Page 4 Place all electronic components on a static-dissipative surface or in a static-shielded bag when they are not in the chassis. CAUTION: Any unverified component could cause unexpected damage. To ensure the correct installation, please always use the components (ex. screws) provided with the accessory box. ACP-2010MB User Manual...
  • Page 5 A Message to the Customer Advantech customer services Each and every Advantech product is built to the most exacting specifica- tions to ensure reliable performance in the harsh and demanding condi- tions typical of industrial environments. Whether your new Advantech...
  • Page 6 Advantech assumes no liability under the terms of this warranty as a consequence of such events. If an Advantech product is defective, it will be repaired or replaced at no charge during the warranty period. For out-of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 7 2010MB mechanically and electrically before shipment. It should be free of marks and scratches and in perfect working order upon receipt. As you unpack the ACP-2010MB, check it for signs of shipping damage. (For example, damaged box, scratches, dents, etc.) If it is damaged or it fails to meet the specifications, notify our service department or your local sales representative immediately.

  • Page 9: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Specifications ..............2 Power Supply Options............3 Table 1.1 Power supply options........ 3 Environment Specifications ..........4 Table 1.2 Environment specifications ...... 4 Dimension Diagram ............5 Figure 1.1 Dimension diagram........5 Chapter 2 System Setup.............8 Removing the Chassis Cover ..........
  • Page 10 Cleaning the Filters ............20 Figure 3.6 Replacing the filters........ 20 Replacing the Power Supply ........... 21 3.5.1 Replacing the Power Supply......... 21 Figure 3.7 Replacing the power supply ....21 Chapter 4 Alarm Module..........24 Alarm Board Layout............24 Figure 4.1 Alarm board layout......... 24 Alarm Board Specifications ..........
  • Page 11 General Information...

  • Page 12: Chapter 1 General Information

    Chapter 1 General Information 1.1 Introduction The ACP-2010MB is a 2U-high rackmount industrial computer chassis. It meets a variety of application needs for filing, printing, e-mails and webserving. This powerful computing platform is suitable for mission- critical computer telephony applications, industrial automation, and fac- tory management.

  • Page 13: Power Supply Options

    1.3 Power Supply Options Table 1.1: Power supply options Model Name 1757000007G 1757000105G 300 W (ATX, PFC) 400 W (ATX, PFC) Watt (single PS/2) (single PS/2) 100 ~ 240 Vac 100 ~ 240 Vac Input rating (Full range) (Full range) +5V @ 35A, +3.3V @ 20A, +5V @ 25A, +3.3V @ 20A, Output voltage...

  • Page 14: Environment Specifications

    10 to 85% @ 40°C, 10 to 95% @ 40°C, Humidity non-condensing non-condensing 1G rms Vibration 10G with 11 ms duration, Shock half sine wave 0 to 3,048 m (0 ~ 10,000 ft) Altitude CE compliant Safety ACP-2010MB User Manual...

  • Page 15: Dimension Diagram

    1.5 Dimension Diagram unit: mm [inch] Figure 1.1: Dimension diagram Chapter 1...
  • Page 17 System Setup...

  • Page 18: Chapter 2 System Setup

    System Setup The following procedures instruct users to install a motherboard, add-on cards, and disk drives into the ACP-2010MB. Refer to Appendix A, the Exploded Diagram and the Parts List for more detailed information about the parts of the ACP-2010MB.

  • Page 19: Installing The Motherboard

    Note: Use caution when installing a motherboard. It's highly recommended to integrate the Advantech motherboard series with the ACP-2010MB to ensure the quality, safety and smooth operation of the air flow design. A yellow label is located inside of the chassis bottom. (see Figure 2.2) The label shows the stand-off bracket locations for attaching...

  • Page 20: Figure 2.3 Stand-Off Bracket

    +12V power connector from the power supply to the motherboard Connect the 9-pin USB wire, PS/2 wire, Power switch wire, and the System Reset switch wire from the chassis to the motherboard. Figure 2.3: Stand-off bracket Figure 2.4: Installing a motherboard ACP-2010MB User Manual...

  • Page 21: Installing Riser Card And Add-On Card

    2.3 Installing Riser Card and Add-on Card ACP-2010MB supports up to 3 add-on cards. To install the add-on card, please install a riser card first. The process is as follows: Insert the riser card on the motherboard. Then, attach it onto the beam on the chassis by fastening the two screws.

  • Page 22: Installing Disk Drives

    2.4 Installing Disk Drives The ACP-2010MB supports one 5.25" optical disk drive and three 3.5" disk drives (one FDD and two internal HDD). Please refer to the follow- ing instructions to install the various disk drives. 2.4.1 Installing HDD, Optical Disk Drive, and FDD To install the internal HDD, 5.25"...

  • Page 23: Figure 2.8 Installing The Optical Disk Drive And 3.5 Fdd

    To install the optical disk drive and 3.5" FDD, undo the screws on the 5.25" disk drive bracket. Undo the screws on each side of the 5.25" disk drive bracket to remove the front covers. Slide the optical disk drive and the FDD into the bracket and fasten it on both sides with the eight screws provided.

  • Page 24: Attaching The Ears And Handles

    To install the handles onto the chassis, refer to Figure 2.9 and attach the ears to the chassis, and the handles to the ears on the front-right and front- left edges with the screws provided. Figure 2.9: Attaching the ears and handles ACP-2010MB User Manual...
  • Page 25 Operation...

  • Page 26: Chapter 3 Operation

    System Reset button: Press this button to reboot the system. Dual USB port: For connecting a wide range of USB devices for data transfer, backup or input. PS/2 connector: For connecting a keyboard or mouse depending on the motherboard design. ACP-2010MB User Manual...

  • Page 27: Led Indicators For System Status

    3.1.2 LED Indicators for System Status Four LEDs are placed on the left side of the front panel to indicate system health and activity. Refer to Table 3.1 for the LED definition summary. Table 3.1: LED indicator functions Description Green Power System power Normal...

  • Page 28: The Rear Panel

    Figure 3.4) Figure 3.4: Rear panel with low profile I/O brackets There is a ground screw with a washer located on the lower right of the rear panel. This will protect the system in case of electrical leakage. ACP-2010MB User Manual...

  • Page 29: Replacing The Cooling Fan

    3.3 Replacing the Cooling Fan There are two easily maintained system cooling fans in the chassis. The fans provide the system with ample cooling by blowing air toward the rear. To replace the fan, proceed as follows: 3.3.1 Replacing the fan Remove the top cover.

  • Page 30: Cleaning The Filters

    To pull out the fan filter, push the hook and slide it rightwards. (see Figure 3.6) Clean the filter with a soft brush or wash the dust away from the filter with fluent water and let it dry thoroughly. Replace them inside the unit. Figure 3.6: Replacing the filters ACP-2010MB User Manual...

  • Page 31: Replacing The Power Supply

    3.5 Replacing the Power Supply The ACP-2010MB supports either a 300W or a 400W PS/2 power supply. To replace the power supply, proceed as follows: 3.5.1 Replacing the Power Supply Unplug the power cord from the power supply. Remove the top cover.
  • Page 33 Alarm Module...

  • Page 34: Chapter 4 Alarm Module

    To stop the alarm beep, press the Alarm Reset button on the front panel and then take the necessary action to fix it. 4.1 Alarm Board Layout The layout and detailed specifications for connectors on the alarm board are shown in this diagram: Figure 4.1: Alarm board layout ACP-2010MB User Manual...

  • Page 35: Alarm Board Specifications

    4.2 Alarm Board Specifications Input Power: +5V, +12V Input Signals: • 7 “fan” connectors • One “thermal sensor” connector (supports up to 8 thermal sensors connected in a series) • One “power good” input • One “alarm reset” input • One “voltage signal”...

  • Page 36: Table 4.3 Cn13, Voltage Detect. Input Connector

    +3.3V signal Pin 7 Power Good Pin 15 +5Vsb signal Pin 8 Power Fail Table 4.7: CN26, HDD LED connector Pin 1 HLED_ACT Pin 2 Table 4.8: FAN1~FAN7, Fan connectors Pin 1 Pin3 FAN_DEC Pin 2 +12V ACP-2010MB User Manual...

  • Page 37: Table 4.9 J1, External Buzzer

    Table 4.9: J1, External buzzer Pin 1 Buzzer Pin 2 Table 4.10: SW1, Fan number select switch Pin 1 Pin 5 Pin 2 FAN_SEL1 Pin 6 FAN_SEL3 Pin 3 Pin 7 Pin 4 FAN_SEL2 Pin 8 RESET Chapter 4...

  • Page 38: Switch Settings

    FAN1 and FAN2. If the two fans are connected to other fan connectors,out of sequence, such as FAN1 and FAN3 or FAN2 and FAN3 or FAN3 and FAN4, instead of FAN1 and FAN2, then the alarm will not function correctly. ACP-2010MB User Manual...

  • Page 39: Thermal Sensor

    4.4 Thermal Sensor The ACP-2010MB is configured with a thermal sensor on the backside of the chassis. (see Figure 4.2) Thermal sensor Figure 4.2: Thermal sensor location Refer to Figure 4.3 for a diagram of the thermal sensor module layout.

  • Page 40: Connector

    Table 4.12: CN1 & CN2, Temperature sensor connector Pin 1 Pin 3 T_SDAT Pin 2 T_SCLK Pin 4 Table 4.13: SW2, Thermal sensor I.D. setting Sensor I.D. SW 1-1 SW 1-2 SW 1-3 SW 1-4 1 (default) ACP-2010MB User Manual...
  • Page 41 Exploded Diagram and Parts List...

  • Page 42: Appendix A Exploded Diagram And Parts List

    20 Power supply 32 PCB guide rail Power button 21 Rear plate 33 Card support beam 10 Reset button 22 Top cover 34 Cooling fan 11 Filter housing 23 I/O bracket 35 Fan bracket 12 Handle 24 Spacer bracket ACP-2010MB User Manual...
  • Page 43 Motherboard and Riser Card Options...

  • Page 44: Appendix B Motherboard And Riser Card Options

    Appendix B Motherboard and Riser Card Options B.1 Motherboard Options The ACP-2010MB supports a variety of Advantech ATX / MicroATX motherboards described below. Contact a local sales representative for more detailed information. Table B.1: ATX motherboard options Model Name PCI/ISA...

  • Page 45: Riser Card Options

    1 (PCIe x16) 1 (PCIe x4) AIMB-554 2 (PCI 32-bit) B.2 Riser Card Options The riser card is specially designed to support Advantech AIMB series of motherboards except AIMB-562 & AIMB-542. Table B.3: Riser card options Expansion Model Name Interface...
