2.1.3 Chassis Front and Rear Sections

The front panel switches behind the door are used for system power, sys-

tem reset 1, system reset 2 (option), alarm reset , power switch, USB and

PS/2 keyboard. A multi-function key lock locks the door cover; user

could lock the door cover by key or without key.

System Reset 1

System Reset 2, Optional

Alarm Reset

Momentary Switch or

Power On/Off Switch

Figure 2.2: Front Panel Switches

USB and PS/2 K/B
