4. Using the Evaluation Platform

4.1 ADV7604 Evaluation Board Hardware

The following features of the ADV7604 evaluation board
Figure 5) should be noted
Input Video Connectors
 4 x HDMI inputs
 1 x Component input
 1 x Graphic input
 2 x D-type inputs (Japanese market only)
Jumpers
 K7 and K8 (external EDID I2C access)
 K6 and K9, K4 and K5, K1 and K2 (not stuffed external EDID I2C access)
 SE_PIN
 SE_PWR
Miscellaneous
 168 pin male motherboard connector
 Power LED (D1)
 I2C header (P1)
